  • Industrial axial wall panel fan | 38" | 27,000 m³/h | 300 W | 3-phase 380–480 V | 0–10 V control | IP55

    Code: ES-5WMB0

    Industrial axial wall panel fan 38": up to 27,000 m³/h, 300 W, 3-phase 380–480 V, 750 rpm, 0–10 V control, SS304 blades, IP55, frame 1122×1122×306 mm. For farms, greenhouses and industry.

  • Industrial axial wall panel fan | 38" | 27,000 m³/h | 300 W | 3-phase 380–480 V | 0–10 V control | IP55

    Large 38-inch axial panel fan for wall mounting: up to 27,000 m³/h at 300 W, 3-phase 380–480 V supply and 0–10 V speed control. Four SS304 stainless steel blades and IP55 protection suit farms, greenhouses and industrial premises.

    Key point:
    A single panel fan moves up to 27,000 m³/h, and the 0–10 V signal allows control from a controller, thermostat or climate system according to temperature or humidity.
    Airflow
    up to 27,000 m³/h
    Power / voltage
    300 W / 3-ph 380–480 V
    Speed
    750 rpm
    Control
    0–10 V, IP55

    We will help you set up speed and automatic control

    We will advise how to adjust this fan's speed and how to switch or control it automatically according to room conditions – humidity, temperature or CO₂ concentration. We will select a suitable speed controller, thermostat, humidity or CO₂ sensor and explain how to connect them.

    Contact us: tel. +370 658 01033 or e-mail info@elsprendimai.eu

    In your e-mail, briefly describe the situation: room purpose and size, fan model and what you want to control – speed, humidity, temperature or CO₂.

    Wholesale quantities: special prices for larger orders. State the required quantity in your e-mail and we will send you an individual offer.

    Operating principle

    The fan with a 1122×1122×306 mm frame is installed in a wall opening. The three-phase 380–480 V, 50–60 Hz motor with ball bearings drives four SS304 stainless steel blades at 750 rpm.

    The 0–10 V control signal allows speed changes from an external controller, thermostat or farm climate computer, and IoT integration lets the fan join a smart system. IP55 protects against dust and water jets.

    Why the 38" panel fan?
    Very high airflow at low power with direct 0–10 V control – efficient ventilation for farms and greenhouses.

    Technical specifications

    Product type Industrial axial wall panel fan
    Code ES-5WMB0
    Fan size 38"
    Airflow up to 27,000 m³/h (15,882 CFM)
    Power 300 W
    Power supply 3-phase, 380–480 V AC, 50–60 Hz
    Speed 750 rpm
    Frame dimensions 1122 × 1122 × 306 mm
    Blades 4 pcs, SS304 stainless steel, 1 mm
    Bearings Ball bearings
    Noise level 69 dB
    Protection rating IP55
    Control 0–10 V signal, IoT integration

    Main functions

    • Very high airflow – up to 27,000 m³/h for large volumes.
    • 0–10 V control – speed can be changed from a controller or climate system.
    • SS304 blades – corrosion-resistant in humid environments.
    • IP55 protection – protection against dust and water jets.
    • Low power – 300 W for a large airflow.

    Where is it used?

    • Production halls and warehouses
    • Farms and livestock buildings
    • Greenhouses
    • Workshops and logistics centres
    • Process heat removal
    • Large commercial premises

    Use by need

    For farmers.
    High airflow for barns and greenhouses, resistant to moisture and dust.
    For manufacturers.
    Efficient removal of heat and polluted air from halls.

    Practical application

    If heat and moisture must be removed from a farm or greenhouse, several 38" panel fans on the end wall together with a 0–10 V climate controller automatically increase or reduce airflow according to temperature and humidity.

    Pros

    • Up to 27,000 m³/h airflow
    • Only 300 W power
    • 0–10 V speed control
    • SS304 stainless steel blades
    • IP55 protection

    Cons / limitations

    • Requires a three-phase 380–480 V supply
    • Large size – the 1122×1122 mm frame needs a solid structure
    • 69 dB noise – intended for industrial and farm buildings
    • Not suitable for small rooms

    Safety and installation notes

    • Installation and connection must be done by a qualified electrician.
    • Protect the motor with a circuit breaker or motor protection.
    • Check the direction of rotation – swap two phases if needed.
    • Fix to a solid structure to avoid vibration.
    • Install with a protective guard in accessible locations.
    • Before maintenance disconnect power and wait until the blades stop.

    Quick selection guide

    38"
    27,000 m³/h
    300 W | 3-ph
    0–10 V
    Suitable when you need:
    • to ventilate a large hall, warehouse or farm
    • to remove process heat
    • a fan for wet and dusty environments
    Check before use:
    • that a three-phase 380 V supply is available
    • that an opening and mounting can be made in the wall
    • that an air inlet is provided
    • how the speed will be controlled
    Important reminder: the 0–10 V signal can come from a climate controller, thermostat or humidity sensor – we will help you choose a solution.

    FAQ

    What voltage is required?
    Three-phase 380–480 V, 50–60 Hz.
    What is the airflow?
    Up to 27,000 m³/h.
    How is the speed controlled?
    With a 0–10 V signal from a controller, thermostat or climate system.
    What are the dimensions?
    Frame 1122 × 1122 × 306 mm.
    What are the blades made of?
    SS304 stainless steel, 1 mm.
    What is the protection rating?
    IP55.

    Panel fan 38" | 27,000 m³/h | 300 W | 0–10 V

    Industrial axial wall panel fan 38": up to 27,000 m³/h, 300 W, 3-phase 380–480 V, 750 rpm, 0–10 V control, SS304 blades, IP55, frame 1122×1122×306 mm. For farms, greenhouses and industry.

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
