IP network audio amplifier–player | 100V | 60W | for PA systems | network audio streaming | local SD playback

Technical Specifications
Audio Playback (SD / IP Network)

Audio formats: MP3 / WMA / PCM
Maximum sampling rate: 48 kHz / 16 bit
Frequency response: 80 Hz – 15 kHz (±3 dB)
Total harmonic distortion (THD): ≤1 %
Signal-to-noise ratio (SNR): ≥77 dB

Amplifier

Rated output power: 60 W
Output: 100 V constant-voltage (PA)
Amplifier efficiency: >90 %
Frequency response: 80 Hz – 15 kHz (±3 dB)
Memory: SD card support up to 32 GB

Electrical Parameters

Power supply: AC 220 V / 50 Hz
Rated power consumption: 95 W
Protections: overcurrent, overheating, overvoltage

Physical Data

Dimensions: 430 × 260 × 66 mm
Net weight: 4.76 kg
Gross weight: 6 kg

Functions

IP network audio streaming – plays audio directly from a central server or network audio collectors
Autonomous operation (offline mode) – scheduled playlists and programs are automatically stored on the SD card and continue playback even if the network connection is lost
Automatic time synchronization – the internal real-time clock synchronizes with the system server, ensuring accurate schedules without manual adjustment
Scheduled and timed playback – precise playback of background music or announcements at predefined times
Background, business and emergency broadcasting – supports three broadcasting levels with priorities; emergency messages always have the highest priority
Watchdog and data error correction – ensures stable, uninterrupted operation and accurate audio transmission

Applications

For users / businesses: Retail stores, cafés, gyms, background music and automatic announcements, reliable operation without complex maintenance
For engineers / designers: IP-based PA and evacuation systems, precise time management and system synchronization, high reliability for critical applications
For installers / integrators: Standard 100 V PA output, compact format for easy cabinet or rack installation, fewer additional components – all functions in one device
Other applications: Schools, hospitals, offices, hotels, industrial facilities, transport and public infrastructure

Advantages

IP + autonomous operation in one device
High audio quality and >90 % efficiency
100 V PA standard – long cable runs with minimal losses
Automatic schedules and backup playback
Reliability for critical systems

Disadvantages

Designed only for fixed 100 V PA systems (not 4–8 Ω)
No Bluetooth (focused on professional solutions)
