  •   IP Network Audio Control Visual Terminal with Touchscreen | Host Override Function | Compatible with DSPPA IP PA System
      IP Network Audio Control Visual Terminal with Touchscreen | Host Override Function | Compatible with DSPPA IP PA System 1
      IP Network Audio Control Visual Terminal with Touchscreen | Host Override Function | Compatible with DSPPA IP PA System 2

    IP Network Audio Control Visual Terminal with Touchscreen | Host Override Function | Compatible with DSPPA IP PA System

    Code: MAG6402
    Inquire about this item
    Price 293.86 € VAT incl.
    ( 242.86 € VAT excl. )
    Want another price? Suggest yours!

    IP network audio control and visual terminal with a touch-sensitive screen, designed for convenient and visual control of IP public address (PA) systems. The device operates as a local control and announcement console, allowing users to select audio sources, play audio files, manage broadcasts, and initiate announcements directly from the wall-mounted terminal.

    Thanks to the touch-sensitive TFT color display, premium design, and simple user interface, the device is suitable for locations where fast and intuitive audio system control is required without the need for a computer or central server.

  • Product description

    Technical specifications

    Type: IP network audio control visual terminal
    Control: Touch-sensitive TFT color display
    Functions: Audio source selection, audio file playback, IP broadcast control
    Compatibility: Fully integrated with DSPPA IP PA system
    Control capabilities: Basic loudspeaker and zone control functions
    Paging: “Host override” – announcements possible even when the system is busy
    Mounting: Wall-mounted
    Design: Modern, premium, suitable for representative spaces

    Functions

    The touch-sensitive TFT display ensures convenient and intuitive operation even for inexperienced users
    Audio source control allows selecting the active audio source and playing music or preloaded audio files with a single touch
    Local paging capability enables voice announcements in selected zones without a central control station
    Priority “Host Override” mode allows announcements even when the system is currently busy – especially important for safety and emergency situations
    Standalone operation without a computer – all main functions are accessible directly from the wall-mounted terminal, no additional equipment required

    Applications

    For administrators / staff: Fast announcement delivery from reception desks, security posts, or administration offices; easy operation without technical knowledge; a clear and aesthetic solution for daily use
    For engineers / system integrators: An excellent additional control point for IP PA systems; reduces dependency on a central control computer; can be installed in multiple zones
    For electricians / installers: Simple wall mounting, clean installation, minimal cabling, fast integration into DSPPA IP infrastructure

    Pros

    Touch-sensitive TFT color display
    Intuitive and easy operation
    Local paging without a server
    Priority “Host override” function
    Modern and representative design
    Suitable for public and commercial spaces

    Cons

    Designed for control only – does not amplify audio
    Operates only within DSPPA IP PA system environment

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
