    Code: MAG6104C
    Inquire about this item
    Price 138.28 € VAT incl.
    ( 114.28 € VAT excl. )
    Want another price? Suggest yours!

    IP network audio output terminal designed for centralized public address (PA), background music, evacuation, and alarm systems. The device operates based on the TCP/IP protocol, ensuring stable, high-quality digital audio transmission over a local or broadband network.

    Thanks to its 1U form factor, extremely low power consumption, and reliable technical parameters, the device is suitable for both residential applications and commercial or industrial projects where flexible and professional audio distribution is required.

  • Product description

    Technical Specifications

    LINE IN (CH1)
    Nominal output: 1 V
    Max. input sensitivity: 4 ±1 V
    Min. input sensitivity: 250 ±50 mV
    Frequency response: 30 Hz – 20 kHz (±3 dB)
    Signal-to-noise ratio: ≥70 dB
    Total harmonic distortion (THD): ≤0.1 %
    Dynamic range: ≥26 dB

    Network audio decoding (MP3)
    Nominal output: 1 V
    Distortion (1 kHz, -10 dB): ≤0.2 %
    Frequency response: 50 Hz – 20 kHz (±3 dB)
    S/N ratio: ≥70 dB

    Network: 1 × Ethernet 10/100 Mbps (auto)
    Power supply: AC 220 V / 50 Hz
    Standby power: 2 W
    Rated power: 2 W

    Dimensions
    Device: 107 × 150 × 44 mm
    19" rack mounting: 483 × 150 × 44 mm (1U)

    Functions
    IP network audio streaming (TCP/IP) – stable digital audio transmission without analog lines
    Background music broadcasting – continuous or zoned audio playback
    Scheduling (timing) tasks – automatic announcements at preset times
    Emergency announcements and alarm – instant activation of audio signals
    EMC AUX IN / EMC AUX OUT – integration with other safety and control systems
    High-quality network decoding – up to 48 kHz / 16-bit digital audio stream
    4 LED status indicators – clear visualization of operating and network status
    1-channel audio output – simple and precise audio distribution

    Applications
    Home users / small facilities: Background music in homes, offices, studios, time announcements or signals without complex installation, stable IP solution without additional amplifiers
    Engineers / system designers: Integration into IP PA / evacuation systems, centralized audio control over the network, high audio quality and precise technical parameters
    Installers / integrators: 1U design for easy 19" rack mounting, low power consumption, simple Ethernet connection
    Other facilities: Schools, hospitals, hotels, shopping centers, industrial sites, administrative buildings

    Pros
    True IP solution – no analog lines
    High audio quality (up to 48 kHz / 16-bit)
    Low power consumption (2 W)
    Compact 1U form factor
    Reliable integration with alarm and PA systems
    Clear LED status indicators

    Cons
    Only 1 audio channel
    No built-in power amplifier
    Designed for use with an external audio system

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
