    Professional IP Network Contact Module | Remote Device Control | with PoE, RS485 and 2 Activation Inputs

    Code: MAG6415
    Inquire about this item
    Price 220.58 € VAT incl.
    ( 182.30 € VAT excl. )
    Want another price? Suggest yours!

    An IP network contact module designed to automate events, control devices remotely, and integrate physical control signals into IP-based audio, security, and building management systems.

    The device supports the TCP/IP protocol, includes 1 RS485 communication channel, 2 trigger inputs, and PoE power, allowing installation anywhere an Ethernet network is available. It is a universal module for modern PA, BMS, security, evacuation, and automation systems.

  • Product description

    Technical Specifications

    • Type: IP Network Trigger Interface
    • Network protocol: TCP/IP
    • Network interfaces: 1 × LAN (Data + PoE)
    • PoE: IEEE802.3af/at, power supplied via Ethernet cable
    • Communication interfaces: 1 × RS485 channel; 2 × Trigger inputs (NO/NC contacts)
    • Installation: Anywhere with Ethernet access
    • Compatibility: DSPPA IP PA system, automation, security, and control platforms

    Functions

    • Trigger integration (2 channels) allows connecting panic buttons, door/occupancy sensors, alarm relay outputs, automation signals, and PLC triggers to a PA system
    • RS485 communication for control or data transfer to devices such as controllers, sensors, and instruments
    • PoE power supply — one cable for both power and communication, extremely easy installation with no need for an external power adapter
    • Universal application, suitable for initiating audio announcements, alarm control, zone activation, or smart automation scenarios

    Use Cases

    • Home user: For control scenarios such as alarms, lighting, door access, announcements; can be connected to buttons or sensors that trigger actions over the IP network.
    • Engineer / System integrator: Ideal tool for smart building management solutions. Trigger → IP functionality enables systems to react to real-world events; compatible with PA, security, BMS, fire safety, and evacuation systems.
    • Electrician / Installer: Very easy installation — PoE power and clearly marked terminals; suitable for both small installations and large systems with multiple control points.

    Pros

    • PoE power simplifies installation
    • 2 trigger inputs provide high flexibility
    • RS485 channel offers wide integration possibilities
    • Compact design, can be installed anywhere
    • Works with any TCP/IP infrastructure
    • Universal application in PA and automation systems

    Cons

    • No audio functions — dedicated only to triggers and RS485
    • Requires a control platform (not a standalone device)
    • Best suited for professional projects, not home-use environments

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
