Rogowski coil integrator (economy class) | 1000 A | 85 mV/kA | 0–333 mVAC | for AC current measurement | S10.1

Technical Specifications

Type: Rogowski coil integrator (economy class)
Model: S10.1
Rated current: 1000 A
Output signal: 0–333 mVAC RMS
Coil transfer ratio: 85 mV/kA
Measurement accuracy: ±1%
Frequency bandwidth: 20 Hz – 10 kHz
Power supply: 6–12 V DC or 24 V DC
Measurement type: AC current only
Design note: The integrator is fixed to the Rogowski coil and becomes inseparable

Functions

Integration of the Rogowski coil signal into a standard 0–333 mVAC RMS output

Compatible with measurement, monitoring, and automation equipment

Cost-effective solution without complex communication interfaces

Wide power supply options (6–12 V DC or 24 V DC)

Stable operation across a wide frequency range

Applications

Home / advanced user:
Energy consumption monitoring in residential or commercial facilities, solution for transmitting measurement data to a central system

Electrician:
Integration into electrical panels, distribution points, and outdoor installations where IP66 protection is required, quick connection to RS485-based systems

Engineer / automation specialist:
Integration with PLC, SCADA, BMS, EMS, and IoT platforms for energy, industrial, infrastructure projects, and OEM solutions with predefined rated current

Advantages

Cost-effective solution for Rogowski-based measurements

Wide range of selectable rated currents (up to 6 kA)

Standard 0–333 mVAC output

Wide frequency bandwidth up to 10 kHz

Compact and easy integration

Limitations

Single rated current only (no switching)

Integrator and coil are inseparable

No digital interfaces (RS485, Modbus, etc.)

Designed for AC current measurement only
