Wall-mounted speaker | 100V | 10W | 92±2dB | engineering plastic housing | 5" driver

Technical Specifications

Manufacturer: DSPPA
Model: DSP106II
Type: Wall-mounted speaker
Power: 1.5–10 W (70V / 100V line system, multiple taps)
Maximum sound pressure level (SPL): 100 ± 2 dB
Sensitivity: 92 ± 2 dB
Effective frequency range: 160 Hz – 18 kHz
Enclosure material: High-quality engineering plastic
Application: Indoor use
Installation: Wall-mounted, multiple connection terminals

Functions

• 70/100V line system with multiple power taps: allows easy adaptation to system load and desired output levels.
• High sensitivity – 92 ± 2 dB: ensures clear voice reproduction, suitable for public address systems even in larger areas.
• Wide frequency range – 160 Hz to 18 kHz: provides balanced performance for background music and announcements.
• Durable engineering-plastic enclosure: resistant to aging, fading, and mechanical impact.

Usage

For household users:
Suitable for home offices, auxiliary rooms, garages, or home paging systems. Easy wall integration with minimal visual impact.

For engineers:
A reliable solution for public facilities such as schools, public institutions, offices, and retail spaces. Suitable for background audio, evacuation announcements, and safety messaging.

For electricians / installers:
Simple and fast wall installation. Multiple power taps allow quick system balancing, convenient for 70/100V network installations.

Advantages

• High maximum SPL (100 ± 2 dB) – maintains clarity even in larger rooms.
• Universal power selection (1.5–10 W) – easy system load adjustment for various projects.
• Durable and lightweight enclosure – engineering plastic ensures long service life and a clean aesthetic.
• Excellent voice clarity – ideal for announcements, paging, and emergency alerts.

Disadvantages

• Frequency response starts at 160 Hz – does not reproduce deep bass; not intended for bass-heavy music.
• Indoor use only – not suitable for outdoor or high-humidity environments.
