  • Supply air ventilation damper in wall | with filter | polyethylene foam thermal insulation | D125 | 0,5m | white | 12,5TOV050-03

    Code: 23046

    Wall supply air valve Ø125 mm / 500 mm with filter, non-return valve and moisture-resistant polyethylene foam insulation. Restores fresh air supply in apartments, houses and offices after window replacement or renovation.

  • Supply air ventilation valve | wall air inlet | with filter | polyethylene foam thermal insulation | D125 | 0,5m | white | 12,5TOV050-03

    Wall supply air valve for bringing outdoor air into a room through an external wall. The kit consists of a Ø125 mm pipe, 500 mm long, sheathed in closed-cell polyethylene foam, and an internal head with a filter and a non-return valve. It is a natural ventilation component for apartments, houses and offices that need a constant supply of fresh air.

    Key point:
    Airtight windows and insulated walls stop natural air infiltration, so extract ventilation in the bathroom or kitchen draws poorly, and moisture and CO₂ build up. This valve creates a controlled air inlet point. Polyethylene foam insulation does not absorb moisture and contains no fibres, so this version is suitable where condensation may occur inside the wall.
    Diameter
    Ø125 mm (internal)
    Pipe length
    500 mm
    Insulation
    PE foam, closed-cell
    Kit contents
    Filter + non-return valve

    How it works

    The valve is installed in a hole drilled through the external wall: the insulated pipe runs through the full wall thickness, the head with the filter is fitted on the inside, and a protective grille covers the opening on the outside.

    When extract ventilation is running in the building (natural, via ducts, or mechanical), a slight negative pressure is created and outdoor air flows in through the valve. The filter traps dust, pollen and insects, while the non-return valve limits backflow and the effect of strong wind gusts.

    The polyethylene foam layer separates the cold pipe surface from the wall material, reducing the thermal bridge and the risk of condensation in the opening.

    Why choose 12,5TOV050-03?
    Compared with the mineral wool versions (12,5TOV050-01, 12,5TOV050-02), PE foam does not absorb water, does not shed dust and releases no fibres, so the insulation retains its properties in damp or cold walls.

    Technical specifications

    Product type Wall supply air valve (air inlet)
    Manufacturer / code Elsp Group / 12,5TOV050-03
    Airflow direction Supply (from outside into the room)
    Installation Through an external wall
    Pipe internal diameter Ø125 mm
    Pipe length 500 mm
    Thermal insulation Polyethylene (PE) foam, closed-cell structure, moisture-resistant
    Internal head With air filter and non-return valve
    Material Plastic
    Colour White
    Spare head 12,5TG (D125, with filter)

    Comparison table: D125 / 0,5 m family

    12,5TOV050-01 Foil-faced mineral wool
    12,5TOV050-02 Mineral wool
    12,5TOV050-03 Polyethylene foam – does not absorb moisture, fibre-free

    Key features

    • Constant air supply – extract ventilation works more effectively, with no need to keep a window ajar.
    • Air filter – traps dust, pollen and insects before the air enters the room.
    • Non-return valve – limits backflow and the effect of wind gusts.
    • PE foam insulation – reduces the thermal bridge and the risk of condensation in the wall opening.
    • Moisture-resistant insulation – closed cells do not absorb water, so properties are retained for a long time.
    • Easy maintenance – the head is removable and the filter can be cleaned; if necessary, the head can be replaced with 12,5TG.

    Where is it used?

    • Living rooms and bedrooms in apartments after window replacement
    • Renovated apartment blocks with natural extract ventilation
    • Detached houses without heat recovery
    • Rooms with a solid fuel boiler or fireplace – to supply combustion air
    • Offices and small commercial premises
    • Country houses and holiday homes, in masonry and timber walls
    • Rooms where moisture or condensation may occur in the wall

    Use by need

    For apartment owners.
    Solves the problem of fogged windows and stuffy air without investing in a heat recovery unit.
    For renovation contractors.
    A standard Ø125 mm component to ensure air supply after window replacement and facade insulation.
    For boiler room installers.
    A simple way to provide a constant air supply to a fuel combustion room.

    Practical application

    If, after PVC windows have been installed, the glass in an apartment fogs up and the bathroom ventilation duct barely draws, a 12,5TOV050-03 valve fitted through the external wall in the bedroom or living room restores the air supply, while the PE foam insulation protects the opening from frost and moisture.

    Pros

    • Complete kit: insulated pipe + head with filter
    • PE foam does not absorb moisture and releases no fibres
    • Non-return valve limits wind gusts
    • Standard Ø125 mm diameter
    • No electricity needed – works passively
    • Replaceable 12,5TG head

    Cons / limitations

    • Pipe length 500 mm – thicker walls require a longer model (e.g. D160 / 1 m)
    • Air is not heated – in the cold season it is worth placing the valve above a radiator
    • Works only together with functioning extract ventilation
    • A clogged filter reduces the air supply – periodic cleaning is required
    • Does not replace heat recovery – heat is not recovered

    Safety and installation notes

    • Before drilling, check that there are no electrical cables, pipes or reinforcement in the wall.
    • Select the core drilling diameter according to the outer diameter of the pipe with insulation (see the dimension drawing).
    • Drill the opening with a slight downward slope towards the outside so that condensate and rainwater do not run inside.
    • Seal the gap between the insulation and the wall to avoid a thermal bridge and air leakage.
    • Always install a protective grille on the outside against rain and birds.
    • In rooms with gas appliances or boilers, coordinate the air supply with the designer – the valve does not replace the regulatory combustion air supply calculation.

    Quick selection guide

    Ø125 mm
    500 mm
    PE foam
    Filter | non-return valve
    Suitable when you need:
    • to restore air supply after window replacement;
    • insulation that is not affected by moisture;
    • a simple, passive solution without electricity.
    Check before use:
    • wall thickness (pipe 500 mm);
    • whether extract ventilation is working;
    • whether there is an external grille to cover the opening.
    Important reminder: the valve does not replace a mechanical ventilation system with heat recovery and does not heat the supply air.

    FAQ

    How does -03 differ from -01 and -02?
    -03 is insulated with polyethylene foam, which does not absorb moisture, whereas -01 and -02 use mineral wool.
    Does the valve need electricity?
    No, it works passively thanks to the pressure difference created by extract ventilation.
    What wall thickness is it suitable for?
    The pipe length is 500 mm, so choose a longer model for thicker walls.
    Where is the best place to install it?
    In a living room, in the upper part of the wall or above a radiator, so that the incoming air warms up.
    How do I maintain the filter?
    Remove the internal head and clean the filter; when worn, replace the head with 12,5TG.
    What else is worth buying for installation?
    A D125 external protective grille and sealing products for the opening – they protect against rain, birds and air leakage.

    Wall supply air ventilation valve D125 | PE foam insulation | 12,5TOV050-03

    Wall supply air valve Ø125 mm, 500 mm, with filter, non-return valve and moisture-resistant polyethylene foam insulation – a simple passive solution for fresh air supply in apartments, houses and offices after window replacement or renovation.
