  •   PoE power adapter | power supply and data transmission | compatible with 802.3af/at/bt | 90W | 10/100/1000 Mbps | CUDYPOE400
      PoE power adapter | power supply and data transmission | compatible with 802.3af/at/bt | 90W | 10/100/1000 Mbps | CUDYPOE400 1
      PoE power adapter | power supply and data transmission | compatible with 802.3af/at/bt | 90W | 10/100/1000 Mbps | CUDYPOE400 2
      PoE power adapter | power supply and data transmission | compatible with 802.3af/at/bt | 90W | 10/100/1000 Mbps | CUDYPOE400 3

    PoE power adapter | power supply and data transmission | compatible with 802.3af/at/bt | 90W | 10/100/1000 Mbps | CUDYPOE400

    Code: CUDYPOE400
    Inquire about this item
    Price 72.60 € VAT incl.
    ( 60.00 € VAT excl. )
    Want another price? Suggest yours!

    This is a high-power professional PoE++ (Power over Ethernet) injector, designed for home, business, and industrial networks that require stable electrical power and data transmission through a single Ethernet cable.
    The device complies with IEEE 802.3af/at/bt standards and delivers up to 90 W output power, making it ideal for IP cameras, access points, network routers, IP phones, industrial controllers, and other PoE devices.
    With its reinforced metal housing, protection against surge, ESD, and electromagnetic interference, and CE/FCC certifications, the Cudy POE400 provides a reliable and safe solution for both office environments and outdoor control cabinets or industrial installations.

  • Product description

    Technical Specifications
    Standards: IEEE 802.3i (10 Mbps), 802.3u (100 Mbps), 802.3ab (1 Gbps), 802.3af (PoE), 802.3at (PoE+), 802.3bt (PoE++)
    Uplink port: 1 × Gigabit Ethernet (GbE)
    Downlink port: 1 × GbE with PoE af/at/bt support
    Pin Assignment: Four-pair transmission
    Maximum distance: up to 100 m (Cat 5e or higher cable)
    LED indicators: Power, PoE Wattage
    Power input: AC 100–240V, 50/60 Hz, 2.2A
    Maximum output power: 90W (54V DC, 1.67A)
    Protections: Surge protection, ESD protection
    Interference protection (EMC/EMI/EMS): EN55032, EN55035 Class A; FCC 47 CFR Part 15B Class A; IEC/EN 61000-4-2: ESD Contact 6kV, Air 8kV; IEC/EN 61000-4-5: Surge 4kV Power/RJ45
    Grounding: via grounding point or 3-pin plug
    Operating temperature: -10°C ~ +40°C
    Storage temperature: -40°C ~ +70°C
    Operating humidity: 10% ~ 90% (non-condensing)
    Certification: CE, FCC certified
    Enclosure: Metal, heat- and impact-resistant
    Mounting: Desktop or wall-mount
    Dimensions: 178 × 80 × 46 mm
    Weight: 665 g

    Features and Benefits
    PoE++ (802.3bt) support: provides up to 90W power output, ideal for high-power devices such as IP cameras with heaters, PTZ cameras, Wi-Fi 6 access points, or PoE routers.
    Automatic protocol detection: compatible with PoE/PoE+/PoE++ – supplies power only to compatible devices.
    Gigabit Ethernet transmission: supports 10/100/1000 Mbps data throughput without performance loss.
    Integrated protection: surge, ESD, and EMI/EMS protection ensures stability and long service life.
    Compact metal housing: enhances heat dissipation and mechanical durability.
    LED indicators: real-time display of power and PoE status.
    Flexible installation: desktop or wall-mounted use.

    Use Cases
    Home users: ideal for powering IP cameras, access points, routers, and VoIP phones without additional adapters.
    Engineers and IT specialists: for network expansion, server rooms, offices, and industrial facilities requiring reliable high-power PoE supply.
    Installers: for IP surveillance, security, alarm, or access control systems using existing Ethernet infrastructure.

    Pros

    High 90W PoE output – supports power-demanding devices

    802.3af/at/bt compatibility – universal usage

    Metal housing for durability and heat management

    Built-in surge and ESD protection

    Silent fanless operation

    Compact and easy to install

    CE and FCC certified

    Cons

    Operating temperature limited to +40°C – not for extreme heat

    Only one PoE output – multiple devices may require more units

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
