  • Modular contactor | 2P | 2NO | 25A | 24VAC | DIN | MCF3 | Promfactor Baltic | MCF32520024 | 4772151000241

    Code: MCF32520024
    Barcode: 4772151000241

    MCF3 25-20 – 2NO (two normally open contacts) modular contactor for DIN rail with a ~24 V AC coil. Rated current 25 A (AC-7a), for motors 8.5 A (AC-7b), width 1 mod. (18 mm). Designed to remotely switch single-phase loads – a water heater, electric heating, a lighting group or ventilation.

  • Modular contactor | 2P | 2NO | 25A | 24VAC | DIN | MCF3 | Promfactor Baltic | MCF32520024 | 4772151000241

    MCF3 25-20 (MCF32520024) – 2NO (two normally open contacts) modular contactor for DIN rail. Designed for remote on/off switching of single-phase loads – a water heater, electric heating, a lighting group or ventilation. Coil ~24 V AC, rated current 25 A (AC-7a), for motors – 8.5 A (AC-7b).

    Key point:
    When a load has to be switched by time, temperature or a signal, a thermostat or time relay cannot carry it directly. The 2NO contactor takes over the power circuit: it disconnects both phase and neutral, leaving the control device to switch only the coil current. The coil is ~24 V AC, so the control circuit can be safety extra-low voltage (via a transformer).
    Current AC-7a (heating, lighting)
    25 A
    Current AC-7b (motors)
    8.5 A
    Coil voltage
    ~24 V AC
    Width in the board
    1 mod. (18 mm)

    Operating principle

    The contactor is mounted on the DIN rail in the distribution board, next to the circuit breaker (MCB) protecting the load. The power circuit is connected to the contact terminals and the control device to coil terminals A1–A2.

    When ~24 V AC is applied to the coil, the electromagnet pulls in the armature: NO contacts close and NC contacts open. When the control voltage is removed, a spring returns the contacts to their initial position. The mechanism operates quietly, so it is also suitable for residential premises.

    This way the control device (time relay, thermostat, photo relay, controller) switches only the small coil current, while the contactor carries the load current.

    Why choose the MCF3 25-20?
    One module handles all switching of a single-phase load: the control device runs without load current, and the water heater or heating is disconnected on both poles.

    Technical specifications

    Product type Modular contactor (DIN rail mounting)
    Manufacturer Promfactor Baltic
    Series / model MCF3 25-20
    Code MCF32520024
    EAN 4772151000241
    Contacts 2NO
    Number of poles 2
    Rated current AC-7a / AC-1 25 A
    Rated current AC-7b (household motors) 8.5 A
    Power AC-7a, 230 V 5.2 kW
    Rated operational voltage (Ue) ~230/400 V
    Coil (control) voltage (Uc) ~24 V AC
    Insulation voltage (Ui) 500 V
    Impulse withstand voltage (Uimp) 4 kV
    Frequency 50/60 Hz
    Utilisation categories AC-1, AC-3, AC-7a, AC-7b
    Width 1 mod. (18 mm)
    Terminal wire cross-section 1–4 mm²
    Terminal tightening torque 0.8 Nm
    Endurance electrical 100,000 cycles / mechanical 1,000,000 cycles
    Operating time 0.05 s
    Degree of protection IP20
    Operating temperature -25…+55 °C
    Storage temperature -25…+70 °C
    Altitude up to 2000 m
    Mounting DIN rail TH35 (35 × 7.5 mm)
    Comb busbar connection not provided
    Auxiliary contacts can be added (MF/AX11 1NO+1NC)
    Standards IEC/EN 61095, IEC/EN 60947-4-1

    Key functions

    • Remote load control – the load is switched by a time relay, thermostat, photo relay or controller via coil A1–A2.
    • Protects the control device from load current – the timer or thermostat contact switches only the coil current.
    • Compact installation – on the DIN rail in the distribution board, 1 mod. (18 mm).
    • Quiet operation – suitable for residential premises and offices.
    • Auxiliary contact – an MF/AX11 (1NO+1NC) can be fitted to the MCF3 for a status signal or interlock.

    Where is it used?

    • Water heater operation on the night tariff (via a time relay)
    • Electric underfloor heating and convectors (via a thermostat)
    • Outdoor and yard lighting groups (via a photo relay / twilight switch or timer)
    • Switching ventilation and heat recovery units
    • Lighting zones in commercial premises
    • Smart home controllers whose relay output is too weak for the load

    Use by customer need

    For homeowners.
    The water heater heats during cheaper tariff hours, and the timer and thermostat last longer because they do not switch the load directly.
    For electricians.
    One module in the board, clearly marked terminals A1–A2 and 1–2 / 3–4 – fast, neat installation.
    For smart system integrators.
    Turns the weak output of a controller or Wi-Fi module into reliable 25 A load switching.

    Practical application

    If the water heater should heat only on the night tariff, a time relay energises the contactor coil A1–A2 during the set hours, and the contactor switches the heater's phase and neutral via contacts 1–2 and 3–4. During the day both poles are open, so the water heater is completely de-energised.

    Pros

    • The control device does not switch the load current – longer service life
    • Mounted on the DIN rail alongside circuit breakers
    • Quiet operation
    • AC-7a and AC-7b currents clearly stated
    • MF/AX11 auxiliary contact can be added

    Cons / limitations

    • Does not protect against overload or short circuit – a circuit breaker is mandatory
    • IP20 – dry distribution boards only
    • Not connectable with a comb busbar
    • AC-7b current (8.5 A) is considerably lower than AC-7a – for larger motors choose a standard AC-3 contactor with a thermal overload relay

    Safety and installation notes

    • A circuit breaker upstream of the contactor is mandatory, selected for the cable and the load. The contactor does not protect the circuit.
    • For motors, check the AC-7b current, not the AC-7a current given in the name; additionally protect the motor with a motor protection circuit breaker or thermal overload relay.
    • The coil voltage (~24 V AC) must match the control voltage – a different voltage will burn out the coil or the contactor will not switch on.
    • Terminal wire cross-section – 1–4 mm², tightening torque – 0.8 Nm.
    • When several contactors next to each other operate continuously (e.g. heating all night), leave a gap or fit a spacer – this reduces heating.
    • Installation and connection to the 230/400 V network must be carried out only by a qualified electrician with the power disconnected.

    Quick selection guide

    25 A AC-7a
    8.5 A AC-7b
    2NO
    ~24 V AC
    1 mod. (18 mm)
    Suitable when you need to:
    • switch a single-phase load by time, temperature or signal
    • disconnect both phase and neutral
    • protect a thermostat or controller contact from load current
    Check before use:
    • the load type: for heating – AC-7a current, for motors – AC-7b current
    • the coil voltage and the control device output
    • space in the board and gaps between continuously operating contactors
    • the circuit breaker upstream of the contactor
    • The coil is AC (~24 V AC) – supply it from a transformer, not from a 24 V DC source
    Important reminder: A contactor only switches the load on and off – it does not replace a circuit breaker, motor protection or a residual current device.

    FAQ

    Does the contactor protect against overload and short circuit?
    No – the circuit is protected by the circuit breaker installed upstream of the contactor.
    Can it control a pump or fan?
    Yes, if the motor operating current does not exceed 8.5 A (AC-7b); for larger motors choose a standard AC-3 contactor.
    Why choose 2NO rather than 1NO?
    2NO disconnects both phase and neutral, so the switched-off load is left completely de-energised.
    How much space does it take in the board?
    1 mod. (18 mm).
    Can the coil be supplied with 24 V DC?
    No, the coil is designed for ~24 V AC; DC voltage is not suitable for it.
    Can an auxiliary contact be added?
    Yes, the MF/AX11 (1NO+1NC) auxiliary contact fits the MCF3 series.

    Modular contactor | 2P | 2NO | 25A | 24VAC | DIN | MCF3 | Promfactor Baltic | MCF32520024 | 4772151000241

    MCF3 25-20 (MCF32520024) – 2NO (two normally open contacts) modular contactor for DIN rail: 25 A (AC-7a), 8.5 A for motors (AC-7b), coil ~24 V AC. Intended for remote control of single-phase loads – a water heater, electric heating, a lighting group or ventilation in a distribution board.

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
