Rotary deflector D160 with flashing | for bitumen roofing | kit with insulated outlet | ABS | grey
Code: S160GRAPrice 156.60 € VAT incl.( 129.42 € VAT excl. )Kit for bitumen roofing: roof flashing 250×160 mm, insulated ventilation outlet 500×160 mm and rotary deflector D160 with ball bearings. Colour – grey.
-
Rotary deflector D160 kit for bitumen roofing – grey
A complete kit for a ventilation outlet through the roof: roof flashing (base) for bitumen roofing, insulated ventilation outlet and rotary deflector. All parts needed for installation – in one box.
Key point
The insulated outlet reduces heat loss and the risk of condensation; the deflector rotates on ball bearings. According to the manufacturer, extraction reaches up to 71 m³/h at a wind speed of 3 m/s. ABS plastic does not rust and is unaffected by moisture, so it is also suitable for aggressive environments – livestock farms, damp rooms, coastal areas.
Connection diameterD160 / 125 mmRoofingBitumenBearingsballColourGrey⚠ For ventilation only
The deflector is intended for ventilation ducts only – to extract humid and warm air. Do not install it on flues of stoves, fireplaces, sauna heaters or boilers: hot flue gases and acidic condensate will damage it, and there is a risk of fire and carbon monoxide (CO) poisoning.
How it works
- The roof flashing is fixed to the roofing and sealed.
- The insulated ventilation outlet is inserted through it, with a Ø125 mm duct connected from below.
- On top – a D160 rotary deflector that extracts air without electricity.
Estimated air extraction
According to the manufacturer – up to 71 m³/h at 3 m/s wind.
Technical specifications
Product type Roof ventilation kit with rotary deflector Roofing Bitumen Kit contents Roof flashing 250×160 mm, insulated outlet 500×160 mm, deflector 160 mm Outer deflector diameter 160 mm Inner connection diameter 125 mm Extraction up to 71 m³/h at 3 m/s wind (manufacturer data) Material ABS plastic, UV-resistant Rotating assembly Ball bearings Weight ~3 kg Colour Grey Where it is used
- Ventilation of detached houses and homesteads
- Bathrooms, kitchens, laundry rooms, boiler rooms
- Garages and outbuildings
- New construction and renovation
Installation diagram: common mistakes and the correct way
☝ Click the diagram to open an enlarged version.⚠ The diagram is for guidance only and may contain inaccuracies. Before installation, check it against the manufacturer's instructions and the roofing requirements.
Responsibility for installation lies with the qualified specialist performing it. UAB „Elektrotechnikos sprendimai“ is not liable for installation or possible errors.☝ Elsprendimai.eu recommends:- If you need only the deflector – rotary deflector D160.
- For a Ø100 duct – rubber adapter D100–125.
✓ Pros
- Everything in the kit – no need to match parts
- Insulated outlet – less condensate
- Ball bearings
- ABS does not rust – suitable for aggressive environments
- Manufacturer-stated capacity – up to 71 m³/h
→ Limitations
- Intended only for bitumen roofing – for other roofing choose a different kit
- Capacity depends on the wind
- Not suitable for flues
⚠ Installation and maintenance
- Check that the kit matches your roofing.
- Seal the roof flashing according to the roofing manufacturer's instructions.
- The outlet must be vertical – level it before final tightening.
- Roof work is work at height.
FAQ
What is included in the kit?
Roof flashing, insulated ventilation outlet and rotary deflector D160.
What duct diameter can be connected?
The inner connection diameter is 125 mm; for a Ø100 duct use an adapter.
How much air does it extract?
According to the manufacturer – up to 71 m³/h at 3 m/s wind.
Is it suitable for aggressive environments?
Yes – ABS plastic does not rust.
In short
Rotary deflector D160 kit for bitumen roofing (grey) – a complete ventilation outlet through the roof in one box, with an insulated outlet and ball bearings. Unsure about the size or roofing? Send us the duct diameter and roof type – we will help you choose.
