  • Automatic transfer switch ATS SaiLingsi SLQ6 | 2P | 63 A | 230 V | PC class

    Code: ES-SLQ6-63A/2
    Price 78.65 € VAT incl.
    ( 65.00 € VAT excl. )
    Buy more, pay less
    10+ pcs.  – 44.04 € for pcs. -44%

    SaiLingsi SLQ6 2P 63 A – automatic transfer switch for a single-phase site. PC class, AC-33B, transfer up to 3 s.

  • Automatic transfer switch ATS SaiLingsi SLQ6 | 2P | 63 A | 230 V | PC class

    SaiLingsi SLQ6 is an automatic transfer switch (ATS) for a single-phase site: main source I and backup II. When the main supply fails, the load is transferred to the backup and returned when it is restored. 2P, 63 A, 230 V.

    Key point
    Compact PC class ATS for a single-phase circuit: manufacturer data Ui 800 V, AC-33B, transfer up to 3.0 s, 6000 mechanical cycles.
    Poles / current
    2P / 63 A
    Voltage monitoring
    1 phase (230 V)
    Transfer
    ≤ 3.0 s
    Terminals
    AC-33B, PC class

    How it works

    The controller monitors the source voltage. When the main source fails and the backup is available, the switch transfers to the backup (up to 3.0 s) and returns when the main source is restored.

    The manufacturer specifies automatic and manual mode.

    Technical specifications

    Type Automatic transfer switch (ATS) with integrated controller
    Manufacturer, model SaiLingsi (Wenzhou) Electronics Co., Ltd – SLQ6-63A/2
    Poles 2P
    Rated current 63 A
    Operating voltage Ue AC 230 V (2P), 50 Hz
    Rated current range 16–63 A
    Insulation voltage Ui AC 800 V
    Class PC
    Utilization category AC-33B
    Transfer time ≤ 3.0 s
    Voltage monitoring Single phase, 230 V
    Terminal arrangement not specified by manufacturer
    Mechanical durability 6000 cycles
    Control Automatic / manual
    Data source SaiLingsi technical information
    ⚠ The brand is SaiLingsi (Wenzhou) Electronics. The table lists only manufacturer-stated parameters; check exact data on the device nameplate.

    Functions

    • Automatic transfer and return
    • Automatic and manual mode
    • PC class, AC-33B
    • Ui 800 V

    Versions and nearest sizes

    • For a three-phase site or higher current choose the SLQ1 series 100–1600 A.

    Applications

    • Single-phase houses and homesteads with a generator
    • Small commercial sites
    • Critical single-phase circuits

    Practical example

    Single-phase house with a 63 A supply and a generator: the grid is connected as the main source, the generator as backup. Circuit breakers are installed upstream of the ATS on both supplies.

    Advantages

    • PC class, Ui 800 V
    • Transfer up to 3.0 s
    • Automatic and manual mode

    Points to note

    • Single-phase circuit only
    • No generator start control specified by manufacturer
    • Short-circuit protection required upstream

    ⚡ Safe installation

    • Installation must be carried out by a qualified electrician with both sources disconnected.
    • Install short-circuit and overload protection upstream of the ATS on both supplies.
    • Select cables or busbars for 63 A and the terminal size.
    • Connect a generator to the building installation only through a transfer switch.
    ☝ Elsprendimai.eu recommends: ATS selection guide · Diagrams: 3P or 4P · Consultation

    How to choose

    Suitable for a single-phase site up to 63 A; short-circuit protection upstream of the ATS.

    2P · 63 A
    1 phase (230 V)
    AC-33B, PC class
    AC-33B · PC
    Suitable if:
    • the site is single-phase
    • current up to 63 A
    Check:
    • protection upstream of the ATS
    • that the site is single-phase
    Important: An ATS is not a protective device – install short-circuit and overload protection separately. If in doubt, consult a qualified electrician.

    Frequently asked questions

    Is it suitable for a three-phase site?
    No, the 2P SLQ6 is for a single-phase circuit. For a three-phase site choose the SLQ1 series.
    How long does the transfer take?
    According to the manufacturer – up to 3.0 s.
    Does it start the generator?
    The manufacturer does not specify this function.
    Can you help with selection?
    Yes. Send us the incoming current and generator power.

    Automatic transfer switch ATS SaiLingsi SLQ6 | 2P | 63 A | 230 V | PC class

    SLQ6 2P 63 A – compact PC class ATS for a single-phase site.

    Illustrative image may have been created using AI. The appearance of the product may differ slightly from the image shown. Please refer to the technical specification.
